KN52 Series Manual Square Zero-Point Quick-Change Plate KN52-108

Description

KN52 Series Manual Square Zero-Point Quick-Change Plate KN52-108
Specifications: 52 hole spacing-manual KN52-108
Clamping force: 18N
Product length: 108
Product material: stainless steel
Handle opening angle: 100°
Installation hole diameter: 10mm
Installation hole spacing: 52mm
Matching screw: M10
Working stroke: 100mm
Handle opening angle: 180°
Product features: quick-change clamp
Scope of application: workpiece positioning and clamping
Product type: general clamp
Product plate thickness: 25mm
Product weight: 1.9KG

 96mm/52mm hole distance zero point quick change plate

*Fast operation.  *Flexible switching.  *Precise positioning.

Use zero-point quick-change system to increase CNC machine tool clamping stations, improve processing capabilities and reduce downtime

Zero point quick change modular installation

The three-axis, four-axis, and five-axis high-precision zero-point fixtures are compatible with quick-release L-bridge plates, self-centering vises, ER collet holders, three-jaw chuck dovetail clamps, and various self-made fixtures, etc., to achieve quick change and quick installation, reduce the pre-machine preparation time, and ensure extremely high precision for repeated clamping of products and changing of processes. It is an upgraded version of the traditional processing technology, and significantly improves product efficiency and quality.
